GTP-020 TDS

Key words:

Classification:

Silicon Sheet

Enquiry hotline:

+8613929499684

Online message

Detail description

PRODUCT DESCRIPTION
GTP-020 Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Their flexibility and elasticity make them suited to the coating of the very uneven surfaces.
Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.

Features and Benefits
● Thermal conductivity 2.0W/m-K
● Very soft & high compressibility
● Natural tacky
● Good Electrically isolating
● Easy to assembly

Applications
● Computer services: CPU,
● Heat sink, Memory modules
● LED Lighting, LCD-TV
● Military Electronics
● Power Supplies
● Telecom services,
● Wireless instruments
● Automotive control services

Availability
● 0.004 inch to 0.4 inch(0.1mm to 10.0mm)
● Stand sheet size is 12＂x 16＂
● FG designates Fiberglass
● DC1 designates proprietary option eliminating tack form one side
● A is meet add addition PSA A1=one side PSA, A2=two side PSA
